Caliper Guides & Seal Repair Kit
- Stock No
- 70-3143
- Brand / Models
-
- Teker & Fren Sistemleri WABCO
- OEM No
- Weight
- 1.000 kg.
Brand | OEM No |
---|---|
DF | 1436853 |
IVC | 42536957 |
WBC | 12 999 699 - 12 999 702 |
TKR | 13C3508276AA |
Product Components
Stock No | Product Name | Pieces | Measures | Weight | |
---|---|---|---|---|---|
3502 | Caliper Guide Pin Ø30 / 91 mm | 1 | Ø30 / 91 mm | 0.300 kg. | |
3501 | Caliper Guide Pin Ø30 / 77,50 mm | 1 | Ø30 / 77,50 mm | 0.230 kg. | |
3513 | Bolt (Long) M16x1,5x90 m | 1 | M16x1,5x90 m | 0.170 kg. | |
1511 | Bolt (Short) M16x1,5/70 mm | 1 | M16x1,5/70 mm | 0.140 kg. | |
1529 | Caliper Pin Bush Ø34x30/20 mm | 2 | Ø34x30/20 mm | 0.030 kg. | |
3531 | Caliper Piston Boot | 1 | 0.030 kg. | ||
3532 | Caliper Pin Boot | 2 | 0.010 kg. | ||
3529 | Caliper Pin Bush Ø34x30x25 mm | 1 | Ø34x30x25 mm | 0.040 kg. | |
3541 | Steel Cap Ø34x16 mm | 2 | Ø34x16 mm | 0.030 kg. | |
3551 | Caliper Plug | 1 | 0.005 kg. |
