Caliper Guides & Seals Repair Kit
- Stock No
- 70-3155
- Brand / Models
-
- Teker & Fren Sistemleri WABCO
- OEM No
- Weight
- 2.100 kg.
Brand | OEM No |
---|---|
WBC | 12 999 738 - 12 999 738VT |
DF | 1505890 |
SCN | 1723418 - 1748132 - 2093080 |
SF | 3 434 3827 01 - 3 434 3827 00 |
SCHMTZ | 1020777 |
SCHWRZMLLR | 46780 |
YRK | 79787365 |
LBHRR | 10326485 |
Product Components
Stock No | Product Name | Pieces | Measures | Weight | |
---|---|---|---|---|---|
3504 | Caliper Guide Pin Ø38 / 118 mm | 1 | Ø38 / 118 mm | 0.780 kg. | |
3503 | Caliper Guide Pin Ø38 / 76 mm | 1 | Ø38 / 76 mm | 0.480 kg. | |
3514 | Bolt (Long) M16x1,5x120 mm | 1 | M16x1,5x120 mm | 0.220 kg. | |
1513 | Bolt (Short) M16x1,5x80 mm | 1 | M16x1,5x80 mm | 0.160 kg. | |
3531 | Caliper Piston Boot | 1 | 0.030 kg. | ||
3533 | Caliper Pin Boot | 2 | 0.020 kg. | ||
3542 | Steel Cap (Short) | 2 | Ø42,5x17 mm | 0.030 kg. | |
3544 | Ring | 4 | Ø44,5x1,25 mm | 0.005 kg. | |
3522 | Caliper Pin Bush Ø42x38 / 30 mm | 3 | Ø42x38 / 30 mm | 0.060 kg. | |
3543 | Steel Cap (Long) Ø42,5x29 mm | 2 | Ø42,5x29 mm | 0.050 kg. | |
3534 | Caliper Pin Boot | 2 | 0.000 kg. | ||
3551 | Caliper Plug | 1 | 0.005 kg. |
